测温范围：-20℃~650℃，搭载640*512像素红外探测器，1.0~8.0连续数字变倍，视场角41.9°×33.3°，波段7.5~14μm。

像元数640×512，像元间距12μm，焦距8mm(F#1.0)，视场角55°×44° ±5%，主要用于钢铁冶金、煤炭化工、电力电网、新能源等。

像元数384×288，像元间距12μm，焦距19mm(F#1.0)，视场角13°×10° ±5%，主要用于钢铁冶金、 煤炭化工、电力电网、新能源等。

产品简述 G系列短波测高温红外热像仪，采用高性能短波红外探测器，适用超高温测温场景。测温范围600℃~2500 […]

Wifi/4G 自动上传到云端，TOF 毫米级激光测距，红外探测器分辨率384×288，测温范围-20℃~550℃(可扩展至650℃)。

Power interface: 796638-2, HDMI interface: fusion video output, steady-state power consumption: two cameras are connected at the same time<6W，MicroUSB接口：支持USB-OTG

The infrared monitoring system of the rotary kiln can solve the problem that the combustion of raw materials, the ring formation in the kiln and the thinning and falling of refractory materials cannot be found in time [...] through the cooperation monitoring inside and outside the kiln

Adopt 12 μ M uncooled infrared focal plane detector, 1280 × 1024 resolution imaging effect is better; Application field: power inspection, petrochemical monitoring, automatic control, fire monitoring, scientific research and testing.

A long wave infrared (8 ~ 14 μ m) The USB in-line thermal image module converts the thermal radiation of the object itself into image and temperature data, and provides SDK for integrated development through mobile app display and data acquisition.

Analog video output: CVBS (PAL), electronic zoom: 1x/2x/4x, infrared camera supports four color palettes, including white hot, black hot, iron red and rainbow.

Ultrasonic vibration sensor interface: sma-ke × 4. Steady state power consumption:<1.5W，SD卡接口：473521001，电源接口：KF2EDGR-3.81-2PW。

Analog video output: CVBS (PAL), contrast and brightness: manual, analog video electronic zoom: 1x/2x/4x, center crosshairs: support.

100Hz high-speed high frame rate infrared thermal imager, which provides client software and SDK development kit, is applied to rail transit, power grid, petroleum and petrochemical, circuit detection, scientific research, security monitoring, machine vision.

With high frame rate design, it can observe fast-moving targets and be applied to power grid, petroleum and petrochemical, rail transit, circuit detection, scientific research, security monitoring, machine vision and customized development.

With a customized macro lens, you can observe subtle targets. The focal length: macro 31mm (f#1.4), which is applied to scientific research institutions, optical fiber testing, nondestructive testing, customized development.

Small size, low power consumption, fast start-up, excellent imaging quality, accurate temperature measurement, applied to power grid, petroleum and petrochemical, rail transit, circuit detection, scientific research, security monitoring, machine vision.

Applied to power grid, petroleum and petrochemical, rail transit, circuit detection, scientific research, security monitoring, machine vision; Number of pixels 384 × 288, field angle 10.7 ° × 8.0 °, focal length 35mm (f#1.0).

Applied to power grid, petroleum and petrochemical, rail transit, circuit detection, scientific research, security monitoring, machine vision, customized development; Temperature measurement accuracy ± 2 ℃ or ± 2%, steady-state power consumption<2.2W。

在化工、制药等行业的危废仓库中，堆积如山的易燃易爆物料如同”定时炸弹”，传统的烟感温感 […]

供稿：胡洁、熊武 在3D打印领域，CO₂激光器因其高精度和高能量密度被广泛应用于选择性激光烧结（SLS）、非金 […]

导语： 在钢铁生产的”心脏”——高炉前，工人们曾这样测温：冒着高温烟尘，用热电偶 […]

导语 你是否想过，看似平凡的结冰现象背后，藏着肉眼看不见的”能量跃动”？我们借助高速红 […]

项目背景：炼铁厂在高炉高风温使用时，热风总管、围管及交接部位出现炉壳开裂、温度过高、变形烧穿、耐火砖脱落等问题 […]
